PTO Drivelines & Adapters

Name Value PTO Product Category Yoke PTO Product Sub Category Tube Yoke Bondioli-Pavesi PTO Series 8 Metric Tube Yoke Bore Size 63 MM Trilobe Cross & Bearing Cap Diameter 1.38 Inch / 34.90mm Cross & Bearing Overall Length 4.19 Inch / 106.50mm Brand Weasler

Irrigation Drive Shaft - Series 1350 x 36" length. 1350/37 Series.HP (65 Diesel Engine) (69 Gas Engine) (79 Electric Motor) Name Value Length 36 Inch Max HP Rating 75 Series 1350

Name Value PTO Product Category Driveshaft PTO Product Sub Category Complete Drive Shaft Bondioli-Pavesi PTO Series 3 PTO Tubing Shape Trilobe Tube Tractor Yoke Size 1-3/8" 6 Spline Tractor Yoke Lock Type Quick Disconnect Driveshaft Implement End 1-3/8"- 6 Spline QD Yoke Compressed Overall Length 40.00 Inches Driveshaft Application Finishing Mower Tractor Yoke Part Number 102-8306 Implement Yoke Part Number 102-8306 Weasler Brand Series Classic Cross & Bearing Cap Diameter 1.06 Inch / 27.0mm Cross & Bearing Overall Length 2.76 Inch / 70.00mm Brand Weasler

Name Value PTO Product Category Driveshaft PTO Product Sub Category Complete Drive Shaft Bondioli-Pavesi PTO Series 5 PTO Tubing Shape Trilobe Tube Tractor Yoke Size 1-3/8" 6 Spline Tractor Yoke Lock Type Quick Disconnect Driveshaft Implement End 1-3/8" Round Yoke Compressed Overall Length 42.00 Inches Driveshaft Application Rotary Cutter Tractor Yoke Part Number 102-6506 Implement Yoke Part Number 802-6535 Weasler Brand Series Classic Cross & Bearing Cap Diameter 1.19 Inch / 30.20mm Cross & Bearing Overall Length 3.13 Inch / 79.40mm Brand Weasler

Name Value PTO Product Category Yoke PTO Product Sub Category Implement Yoke Walterscheid Metric PTO Series 2300 Bondioli-Pavesi PTO Series 4 Implement Yoke Bore Shape Round Implement Yoke Bore Size 1-3/8 Inch Center of Bearing to End of Yoke 95.00 mm / 3.74 Inch Cross & Bearing Cap Diameter 1.06 Inch / 27.0mm Cross & Bearing Overall Length 2.94 Inch / 74.60mm Brand Weasler

Metric Cross and Bearing Kit - Type 2 (Snap Ring Grooves in Yokes) Specs: PTO Product Category: Cross and Bearing Kit PTO Product Sub Category: Cross and Bearing Kit - Standard Duty Cross & Bearing Cap Diameter: 1.19 Inch / 30.20mm Bondioli-Pavesi PTO Series: 6 Walterscheid Metric PTO Series: 220 Cross & Bearing Overall Length: 3.62 Inch / 92.00mm Brand: Tru-Power

Name Value PTO Product Category Yoke PTO Product Sub Category Tube Yoke Bondioli-Pavesi PTO Series 5 Metric Tube Yoke Bore Size 52 MM Trilobe Cross & Bearing Cap Diameter 1.19 Inch / 30.20mm Cross & Bearing Overall Length 3.13 Inch / 79.40mm Brand Weasler

Name Value PTO Product Category Guard PTO Product Sub Category Guard Repair Kit PTO Guard Type 250 Inner Shield Bearing ID 52.80 MM ( 2.08" ) Inner Shield Bearing OD 71.40 MM ( 2.81" ) Outer Shield Bearing ID 52.80 MM ( 2.08" ) Outer Shield Bearing OD 71.40 MM ( 2.81" ) Brand Weasler

Name Value Product Type PTO Adapter Attachment Retracting Sleeve QD Female End(s) 1-3/8 Inch 21 Spline Male End(s) 1-3/8 Inch 6 Spline PTO Connection Type Female - Male Extends PTO Length 5-1/8 Inch Overall Length 7-1/8 Inch Brand AgSmart

Name Value PTO Product Category Shafting and Tubing PTO Product Sub Category Lemon Tube Length Meters 1 Length Inches 39.37 Outside Diameter MM 48 Outside Diameter Inch 1.89 Wall Thickness MM 3.8 Wall Thickness Inch 0.15 Brand Weasler Inside Diameter Inch 1.575 Walterscheid Metric PTO Series 220 Walterscheid Metric PTO Series 2400

Name Value PTO Product Category Yoke PTO Product Sub Category Shaft Yoke North American PTO Series 12 Yoke Bore Size 1 x 1-1/8 Center of Bearing to End of Yoke 3-3/8 Inch Cross & Bearing Cap Diameter 1-1/16 Inch / 27.00mm Cross & Bearing Overall Length 2-1/2 Inch / 63.50mm Brand Weasler

Name Value Cross & Bearing Cap Diameter 15/16 Inch / 23.88mm Cross & Bearing Overall Length 2-23/64 Inch / 59.94mm PTO Product Category Cross and Bearing Kit North American PTO Series 1000 PTO Product Sub Category Cross and Bearing Kit - Standard Duty Brand Weasler

Name Value PTO Product Category Yoke PTO Product Sub Category Tube Yoke Bondioli-Pavesi PTO Series 3 Metric Tube Yoke Bore Size 43 MM Trilobe Cross & Bearing Cap Diameter 1.06 Inch / 27.0mm Cross & Bearing Overall Length 2.76 Inch / 70.00mm Brand Weasler

For Bondioli 247006351, John Deere DC38275, Vermeer 106416017, Woods 7280 Name Value Outside Diameter 6.31 Inches Inside Diameter 4.002 Inches Thickness .125 Inch Brand AgSmart

Kwik-D-Tach Adapter - Rotates 30-degrees by hand for quick release Name Value Product Type PTO Adapter Attachment Rotating Sleeve QD Female End(s) 1-3/8 Inch 6 Spline Male End(s) 1-3/8 Inch 21 Spline PTO Connection Type Female - Male Extends PTO Length 4-5/16 Inch Overall Length 6-1/2 Inch Max HP Rating 75 Brand AgSmart
