PTO Drivelines & Adapters

Name Value Bondioli-Pavesi PTO Series 1 PTO Product Category Driveshaft PTO Product Sub Category Complete Drive Shaft Compressed Overall Length 40 Inch Driveshaft Application All Purpose Driveshaft Implement End 1-3/8"- 6 Spline QD Yoke PTO Tubing Shape Trilobe Tube Tractor Yoke Lock Type Quick Disconnect Tractor Yoke Size 1-3/8" 6 Spline Brand Tru-Power

Cross and Bearing for 1410 drivelines. Commonly used in irrigation units. Outside snap rings, 4.187" cap to cap, 1.187" cap diameter. Name Value Series 1410

Name Value PTO Product Category Driveshaft PTO Product Sub Category Complete Drive Shaft Bondioli-Pavesi PTO Series 5 PTO Tubing Shape Trilobe Tube Tractor Yoke Size 1-3/8" 6 Spline Tractor Yoke Lock Type Safety Slide Lock Driveshaft Implement End 1-3/8"- 6 Spline QD Yoke Compressed Overall Length 46.00 Inches Driveshaft Application Rotary Cutter Tractor Yoke Part Number 102-6506 Implement Yoke Part Number 102-6506 Weasler Brand Series Classic Cross & Bearing Cap Diameter 1.19 Inch / 30.20mm Cross & Bearing Overall Length 3.13 Inch / 79.40mm Brand Weasler

Name Value PTO Product Category Yoke PTO Product Sub Category Shaft Yoke North American PTO Series 55 Yoke Bore Size 1-5/16 Square Center of Bearing to End of Yoke 4-1/8 Inch Cross & Bearing Cap Diameter 1-17/32 Inch / 38.86mm Cross & Bearing Overall Length 4-5/16 Inch / 109.55mm Brand Weasler

Name Value PTO Product Category Yoke PTO Product Sub Category Implement Yoke North American PTO Series 6 Implement Yoke Bore Shape Round Implement Yoke Bore Size 1-1/4 Inch Center of Bearing to End of Yoke 2-1/2 Inch Keyway Size 1/4 x 5/16 Double Keyway Cross & Bearing Cap Diameter 31/32 Inch / 24.61mm Cross & Bearing Overall Length 2-9/32 Inch / 57.94 mm Brand Weasler

Heat-treated alloy steel, rust preventative finish - Set screws furnished Name Value Product Type PTO Adapter Attachment Set Screw Female End(s) 1-3/8 Inch 21 Spline Male End(s) 1-3/8 Inch 21 Spline PTO Connection Type Female - Male Extends PTO Length 4-13/16 Inch Overall Length 6-7/8 Inch Max HP Rating 125 Brand AgSmart

Name Value PTO Product Category Yoke PTO Product Sub Category Roll Pin Diameter - MM 10.00 Diameter - Inch .39 Length - MM 90.00 Length - Inch 3.54 Brand Weasler

Name Value PTO Product Category Yoke PTO Product Sub Category Shaft Yoke North American PTO Series 6 Yoke Bore Size 3/4 x 7/8 Center of Bearing to End of Yoke 2-1/2 Inch Brand Weasler

Name Value PTO Product Category Driveshaft PTO Product Sub Category Complete Drive Shaft Bondioli-Pavesi PTO Series 4 PTO Tubing Shape Trilobe Tube Tractor Yoke Size 1-3/8" 6 Spline Tractor Yoke Lock Type Quick Disconnect Driveshaft Implement End 1-1/4" Round Yoke Compressed Overall Length 53.00 Inches Driveshaft Application Post Hole Digger Tractor Yoke Part Number 102-8406 Implement Yoke Part Number 802-8420 Weasler Brand Series Classic Cross & Bearing Cap Diameter 1.06 Inch / 27.0mm Cross & Bearing Overall Length 2.94 Inch / 74.60mm Brand Weasler

Name Value Bondioli-Pavesi PTO Series 2 PTO Product Category Driveshaft PTO Product Sub Category Complete Drive Shaft Compressed Overall Length 60 Inch Driveshaft Application All Purpose Driveshaft Implement End 1-1/4" Round Yoke PTO Tubing Shape Trilobe Tube Tractor Yoke Lock Type Quick Disconnect Tractor Yoke Size 1-3/8" 6 Spline Brand Tru-Power

Name Value PTO Product Category Yoke PTO Product Sub Category Tractor Yoke Bondioli-Pavesi PTO Series 1 Tractor Yoke Size 1-3/8" 6 Spline Tractor Yoke Lock Type Quick Disconnect Cross & Bearing Cap Diameter .87 Inch / 22.00mm Cross & Bearing Overall Length 2-1/8 Inch / 54.00mm Brand Weasler

55 Series Tube Weld Yoke for 2 1/2" O.D. round tube (.134 wall). Name Value PTO Product Category Yoke PTO Product Sub Category Tube Yoke North American PTO Series 55 Cross & Bearing Cap Diameter 1-17/32 Inch / 38.86mm Cross & Bearing Overall Length 4-5/16 Inch / 109.55mm Brand Weasler

Weasler Forged 44 Series Tractor PTO Yoke - 1 3/8", 21 spline Quick Disconnect. Name Value PTO Product Category Yoke PTO Product Sub Category Tractor Yoke North American PTO Series 44 Tractor Yoke Size 1-3/8" 21 Spline Tractor Yoke Lock Type Quick Disconnect Cross & Bearing Cap Diameter 1-5/16 Inch / 33.35mm Cross & Bearing Overall Length 4 Inch / 101.60mm Brand Weasler

Name Value PTO Product Category Yoke PTO Product Sub Category Implement Yoke North American PTO Series 12 Implement Yoke Bore Shape Round Implement Yoke Bore Size 1-1/4 Inch Center of Bearing to End of Yoke 3-1/2 Inch Keyway Size 1/4 x 5/16 Double Keyway Cross & Bearing Cap Diameter 1-1/16 Inch / 27.00mm Cross & Bearing Overall Length 2-1/2 Inch / 63.50mm Brand Weasler

Quick Disconnect Tractor Yoke - 1 3/8" x 6 spline Name Value PTO Product Category Yoke PTO Product Sub Category Tractor Yoke Walterscheid Metric PTO Series 2500 Tractor Yoke Size 1-3/8" 6 Spline Tractor Yoke Lock Type Quick Disconnect Cross & Bearing Cap Diameter 1.42 Inch / 36.00mm Cross & Bearing Overall Length 3.50 Inch / 88.80mm Brand Weasler
