Tillage Parts

20.4 X 4.5MM RIPPLE COULTER Rippled Flutes extend through the edge of the blade.   If prefer blade with smooth edge - order # 845-F204512  Application Coulter - Ripple Bolt Circle 5 and 5-1/4 Inch Coulter Center Hole 4 Inch Diameter 20 Inch Edge Ripple For Bolt Size 1/2 Inch Hole Type Bolt Holes Number of Bolt Holes 4 Holes Thickness - Inch or Gauge 7 Gauge Thickness - MM 4.5 MM Wear Tuff Coat No Brand Ingersoll

20 X 4.5MM RIPPLE COULTER

20 X 4.5MM RIPPLE COULTER FOR UNVERFERTH ALSO FITS RAWSON. Application Coulter - Ripple Bolt Circle 5 Inch Concavity Specification 3/8 Inch Coulter Center Hole 3.8 Inch Diameter 20 Inch Edge Ripple For Bolt Size 3/8 Inch Hole Type Bolt Holes Number of Bolt Holes 6 Holes Thickness - Inch or Gauge 7 Gauge Thickness - MM 4.5 MM Wear Tuff Coat No Brand Ingersoll

RIPPLE COULTER 20" 4.5MM-KMC REPLACES KMC 03-050-042 VINE-CUTTER APPLICATION Application Coulter - Ripple Bolt Circle 3.63 Inch Coulter Center Hole 2-1/2 Inch Diameter 20 Inch Edge Ripple For Bolt Size 3/8 Inch Hole Type Bolt Holes Number of Bolt Holes 4 Holes Thickness - Inch or Gauge 7 Gauge Thickness - MM 4.5 MM Wear Tuff Coat No Brand Ingersoll

20 X 4.5MM RIPPLE COULTER FOR DMI & KMC USED ON KMC, MELROE, WILRICH, DMI, BIGHAM BROS, TYE, LANDOLL, KRAUSE, UFT AND MANY OTHERS. REPLACES DMI 33502043, KMC 16-050-004, KRAUSE 30-251. Application Coulter - Ripple Bolt Circle 5 Inch Coulter Center Hole 3-11/16 Inch Diameter 20 Inch Edge Ripple For Bolt Size 1/2 Inch Hole Type Bolt Holes Number of Bolt Holes 4 Holes Thickness - Inch or Gauge 7 Gauge Thickness - MM 4.5 MM Wear Tuff Coat No Brand Ingersoll

RIPPLE COULTER 17X4.5MM REPLACES KMC 16-050-007 Application Coulter - Ripple Bolt Circle 5 and 5-1/4 Inch Coulter Center Hole 4 Inch Diameter 17 Inch Edge Ripple For Bolt Size 1/2 Inch Hole Type Bolt Holes Number of Bolt Holes 8 Holes Thickness - Inch or Gauge 7 Gauge Thickness - MM 4.5 MM Wear Tuff Coat No Brand Ingersoll

16.7 X 4MM RIPPLE COULTER FOR KMC REPLACES KMC 03-050-010. Application Coulter - Ripple Bolt Circle 3.63 Inch Coulter Center Hole 2-1/2 Inch Diameter 17 Inch Edge Ripple For Bolt Size 3/8 Inch Hole Type Bolt Holes Number of Bolt Holes 4 Holes Thickness - Inch or Gauge 8 Gauge Thickness - MM 4.0 MM Wear Tuff Coat No

16 X 4MM RIPPLE COULTER - 5 HOLE Application Coulter - Ripple Bolt Circle 4-3/4 Inch Coulter Center Hole 2-1/8 Inch Diameter 16 Inch Edge Ripple For Bolt Size 1/2 Inch Hole Type Bolt Holes Number of Bolt Holes 5 Holes Thickness - Inch or Gauge 8 Gauge Thickness - MM 4.0 MM Wear Tuff Coat No Brand Osmundson

RIPPLE COULTER 16" 4MM-YETTER REPLACES YETTER 2571-161 Application Coulter - Ripple Bolt Circle 5-1/4 Inch Coulter Center Hole 4 Inch Diameter 16 Inch Edge Ripple For Bolt Size 1/2 Inch Hole Type Bolt Holes Number of Bolt Holes 4 Holes Thickness - Inch or Gauge 8 Gauge Thickness - MM 4.0 MM Wear Tuff Coat No Brand Osmundson

28 X 8MM PLAIN COULTER - 5 HOLES ON 5.5" Has 4.05" center hole and 5 holes on 5-1/2" centers for 1/2" bolts. UPC 847810089128

24 X 5MM PLAIN COULTER FOR DMI 3-11/16" center hole and 4 holes for 1/2" bolts on 5" circle. Works on Landoll and DMI.

22 X 6MM PLAIN COULTER - 1-1/2" ROUND Application Coulter - Smooth Axle Size 1-1/2 Inch Round Bolt Circle None Diameter 22 Inch Edge Smooth For Bolt Size Center Hole Only Hole Type Single Punch Number of Bolt Holes Center Hole Only Thickness - Inch or Gauge 1/4 Inch Thickness - MM 6.0 MM Wear Tuff Coat No

22 X 6MM FLAT COULTER WITH 5 ON 4-1/2"

22 X 4.5MM PLAIN COULTER FITS CASE IH ECOLO TILL 2500 RIPPER. REPLACES CIH 33635A1 AND 33502240. Application Coulter - Smooth Bolt Circle 5 Inch Coulter Center Hole 3-11/16 Inch Diameter 22 Inch Edge Smooth For Bolt Size 1/2 Inch Hole Type Bolt Holes Number of Bolt Holes 4 Holes Thickness - Inch or Gauge 7 Gauge Thickness - MM 4.5 MM Wear Tuff Coat No

20 X 6MM PLAIN COULTER - 1-1/2" ROUND Fits JD 710, 712 Mulch Tiller, Glencoe/Farmland Soil Saver, DMI, Case, Bush Hog Soil Hog, Hiniker and others. Application Coulter - Smooth Axle Size 1-1/2 Inch Round Bolt Circle None Diameter 20 Inch Edge Smooth For Bolt Size Center Hole Only Hole Type Single Punch Number of Bolt Holes Center Hole Only Thickness - Inch or Gauge 1/4 Inch Thickness - MM 6.0 MM Wear Tuff Coat No
