Combine

Chopper Straw - Grain Saver, Air Flow Lower & without Chopper Models/Applications: L2-L3 (S/N 17501 & above), L2-L3 (S/N 17501 & above), M, M2-M3 (S/N 19901 & above), MH2, MH3 Replaces: 71300867 Belt, C, 0.875 x 194in OC Specifications Angle 40 Cord Type Polyester Effective Length (in) 192.6 Effective Length (mm) 4892 Notched false Section C Outside Circumference (in) 194 Outside Circumference (mm) 4927.6 Top Width (in) 0.875 Top Width (mm) 22.2

Cylinder Drive 804-1318 RPM & Traction Drive, Hydro (2V) D2900 (649T) Models/Applications: L2-L3 (S/N 17501-28000), M2-M3 (S/N 19901-25900) Replaces: 71188635 Belt, BK2, 1.48 x 118in OC, 2 Band Specifications Angle 40 Cord Type Aramid - Kevlar Effective Length (in) 0 Effective Length (mm) 0 Notched false Section BK Outside Circumference (in) 118 Outside Circumference (mm) 2997.2 Top Width (in) 1.5 Top Width (mm) 38.1

Main Drive Models/Applications: K2, F2 (Gas), F3 (Gas), L (Diesel), M (Diesel), M2, M3, MH2, MH3 Gas  Replaces: 71153532 Belt, BK2, 1.48 x 163in OC, 2 Band Specifications Angle 40 Cord Type Aramid - Kevlar Effective Length (in) 0 Effective Length (mm) 0 Notched false Section BK Outside Circumference (in) 163 Outside Circumference (mm) 4140.2 Top Width (in) 1.5 Top Width (mm) 38.1

Cylinder 387-1343 RPM, Traction Drive, Hydro Models/Applications: K, K2 Replaces: 71147546 Belt, BK2, 1.48 x 98in OC, 2 Band Specifications Angle 40 Cord Type Aramid - Kevlar Effective Length (in) 0 Effective Length (mm) 0 Notched false Section BK Outside Circumference (in) 98 Outside Circumference (mm) 2489.2 Top Width (in) 1.5 Top Width (mm) 38.1

Pivot, RH Models/Applications: E3, K, K2 Replaces: 71139966 Belt, HKK, 1.5 x 124.9in OC Specifications Angle 30 Cord Type Aramid - Kevlar Effective Length (in) 0 Effective Length (mm) 0 Notched false Section HKK Outside Circumference (in) 0 Outside Circumference (mm) 0 Top Width (in) Top Width (mm)

Traction Drive, Non-Hydro Models/Applications: E3, K  Replaces: 71139963 Belt, HKK, 1.5 x 94.1in OC Specifications Angle 30 Cord Type Aramid - Kevlar Effective Length (in) 0 Effective Length (mm) 0 Notched false Section HKK Outside Circumference (in) 0 Outside Circumference (mm) 0 Top Width (in) Top Width (mm)

Return Auger & Walker  Models/Applications:410, 510, 550 Replaces: 227986M2 Belt, B/5L, 0.656 x 181in OC Specifications Angle 40 Cord Type Polyester Effective Length (in) 179.4 Effective Length (mm) 4556.8 Notched false Section B/5L Outside Circumference (in) 181 Outside Circumference (mm) 4597.4 Top Width (in) 0.656 Top Width (mm) 16.7

Cylinder Drive  Models/Applications: 410, 510, 550  Replaces: 226981M1 Belt, HLK, 1.75 x 91.5in OC Specifications Angle 30 Cord Type Aramid - Kevlar Effective Length (in) 0 Effective Length (mm) 0 Notched false Section HLK Outside Circumference (in) 0 Outside Circumference (mm) 0 Top Width (in) Top Width (mm)

Grain Tank Unloader Drive Models/Applications: 1680 (S/N JJC0115352 & above),1688, 2188, 2377, 2388, 2577, 2588  Replaces: 1989217C1 Belt, CK, 0.875 x 146in OC Specifications Angle 40 Cord Type Aramid - Kevlar Effective Length (in) 144.6 Effective Length (mm) 3672.8 Notched false Section CK Outside Circumference (in) 146 Outside Circumference (mm) 3708.4 Top Width (in) 0.875 Top Width (mm) 22.2

Cleaning Fan Drive  Models/Applications: 1440, 1460, 1480, 1640, 1660 (w/o extended length cleaning system), 1680  Replaces: 195396C2 Belt, HJP, 1.25 x 74in OC Specifications Angle 30 Cord Type Polyester Effective Length (in) 0 Effective Length (mm) 0 Notched false Section HJP Outside Circumference (in) 0 Outside Circumference (mm) 0 Top Width (in) Top Width (mm)

Feeder Drive & Feeder Drive without Rock Trap Models/Applications: 1480, 1680, 1688, 2188, 2377, 2388, 2577, 2588  Replaces: 194528C1 Belt, C2, 2.99 x 143in OC, 3 Band Specifications Angle 40 Cord Type Polyester Effective Length (in) 0 Effective Length (mm) 0 Notched false Section C2 Outside Circumference (in) 143 Outside Circumference (mm) 3632.2 Top Width (in) 2.991 Top Width (mm) 76

Auger & Knife Drive - Fan Jackshaft Drive - Cleaning Fan Jackshaft Drive - Drive Over Center (112" O.D. BELT) Models/Applications: 715, 820, 1440, 1460, 1640, 1660, 1644, 1666, 2144, 2166, 2344, 2366 (Prior to S/N JJC0184544)  Replaces: 191305C1 Belt, C, 0.875 x 112in OC Specifications Angle 40 Cord Type Polyester Effective Length (in) 110.6 Effective Length (mm) 2809.2 Notched false Section C Outside Circumference (in) 112 Outside Circumference (mm) 2844.8 Top Width (in) 0.875 Top Width (mm) 22.2

Grain Tank Unloader Drive  Models/Applications:1440, 1460, 1640, 1660 (Prior to S/N JJC0102897), 2144, 2166, 2344, 2366  Replaces:191290C1 Belt, C, 0.875 x 134in OC Specifications Angle 40 Cord Type Polyester Effective Length (in) 132.6 Effective Length (mm) 3368 Notched false Section C Outside Circumference (in) 134 Outside Circumference (mm) 3403.6 Top Width (in) 0.875 Top Width (mm) 22.2

Auxiliary Pump Drive, Clean Grain Elevator Drive, Sickle & Auger Drive Models/Applications: 1420, 1440, 1460, 1480, 1660 (w/Navistar engine), 1680 (Prior to S/N JJC0045689), 2450, 2550, TR70, TR75, TR85, TR86, TR87, TR88  Replaces: 191288C2 Belt, C, 0.875 x 97in OC Specifications Angle 40 Cord Type Polyester Effective Length (in) 95.6 Effective Length (mm) 2428.2 Notched false Section C Outside Circumference (in) 97 Outside Circumference (mm) 2463.8 Top Width (in) 0.875 Top Width (mm) 22.2

Separator Drive Models/Applications: 1480, 1680 (Prior to S/N JJC0045689)  Replaces: 191244C1 Belt, BK2, 2.21 x 146in OC, 3 Band Specifications Angle 40 Cord Type Aramid - Kevlar Effective Length (in) 0 Effective Length (mm) 0 Notched false Section BK Outside Circumference (in) 146 Outside Circumference (mm) 3708.4 Top Width (in) 2.25 Top Width (mm) 57.2
