Combine

Header and Real Pump (Standard Capacity) Models/Applications: 9400 (S/N 635101 & above), 9410, 9450, 9500, 9500SH (S/N 635201 & above), 9501, 9510, 9510SH, 9550, 9550SH, 9560, 9560SH, 9650, 9660, CTS, CTS II, CTS RICE Replaces: H151952 Belt, D, 1.25 x 169in OC Specifications Angle 40 Cord Type Polyester Effective Length (in) 166.2 Effective Length (mm) 4221.5 Notched false Section D Outside Circumference (in) 169 Outside Circumference (mm) 4292.6 Top Width (in) 1.25 Top Width (mm) 31.8

Cooling Fan (Low Power) Models/Applications: 9410, 9450, 9500, 9510, 9510SH, 9600 (Prior to S/N 641717) Replaces: H132808 Belt, B/5L, 0.656 x 56in OC Specifications Angle 40 Cord Type Polyester Effective Length (in) 54.4 Effective Length (mm) 1381.8 Notched false Section B/5L Outside Circumference (in) 56 Outside Circumference (mm) 1422.4 Top Width (in) 0.656 Top Width (mm) 16.7

Secondary Countershaft Models/Applications: 9400, 9410 (High Power), 9450, 9500, 9500SH, 9501, 9510, 9510SH, 9550, 9550SH, 9560, 9560SH, 9600, 9610, 9650, 9660, CTS, CTS II, CTS RICE, T660, T670 Replaces: H128010 Belt, C, 0.875 x 192in OC Specifications Angle 40 Cord Type Polyester Effective Length (in) 190.6 Effective Length (mm) 4841.2 Notched false Section C Outside Circumference (in) 192 Outside Circumference (mm) 4876.8 Top Width (in) 0.875 Top Width (mm) 22.2

Chopper in Rear Operating Position (Long) Models/Applications: 9500, 9500SH, 9501, 9510, 9510SH, 9600, 9610 Replaces: H125381 Belt, C, 0.875 x 175in OC Specifications Angle 40 Cord Type Polyester Effective Length (in) 173.6 Effective Length (mm) 4409.4 Notched false Section C Outside Circumference (in) 175 Outside Circumference (mm) 4445 Top Width (in) 0.875 Top Width (mm) 22.2

Feeder Conveyor (Long Feeder House) & Chopper, Front Models/Applications: 6600, 6620 (Prior to S/N 403301), 7700, 7720 (Prior to S/N 409101), 8820, 9400, 9410, 9500, 9500SH, 9501, 9510, 9510SH, 9600, 9610 Replaces: H125380 Belt, C, 0.875 x 188in OC Specifications Angle 40 Cord Type Polyester Effective Length (in) 186.6 Effective Length (mm) 4739.6 Notched false Section C Outside Circumference (in) 188 Outside Circumference (mm) 4775.2 Top Width (in) 0.875 Top Width (mm) 22.2

Tailings Auger Drive Models/Applications: 6620, 6622, 7720, 7721, 8820 Replaces: H118730 Belt, C, 0.875 x 132in OC Specifications Angle 40 Cord Type Polyester Effective Length (in) 130.6 Effective Length (mm) 3317.2 Notched false Section C Outside Circumference (in) 132 Outside Circumference (mm) 3352.8 Top Width (in) 0.875 Top Width (mm) 22.2

Cylinder Drive, Reg Dual and Single Range, STD (240-960 RPM) Models/Applications: 9400, 9410, 9450, 9500, 9501, 9500SH, 9510, 9510SH, 9550, 9550SH, 9600, 9610, 9650, 9660, T660, T670, CTS, CTS II, CTS RICE (111.5" O.D. Belt) Replaces: H115881 Belt, BK2, 2.95 x 111in OC, 4 Band Specifications Angle 40 Cord Type Aramid - Kevlar Effective Length (in) 0 Effective Length (mm) 0 Notched false Section BK Outside Circumference (in) 111 Outside Circumference (mm) 2819.4 Top Width (in) 3 Top Width (mm) 76.2

Cylinder, Intermediate Shaft -- Countershaft Drive, Torque-Sensing Models/Applications: 6600, 6620, 6622, 7700, 7720, 7721, 8820 Replaces: H113749 Belt, HMK, 2 x 91.5in OC Specifications Angle 30 Cord Type Aramid - Kevlar Effective Length (in) 0 Effective Length (mm) 0 Notched false Section HMK Outside Circumference (in) 0 Outside Circumference (mm) 0 Top Width (in) Top Width (mm)

Feeder House, Variable Conveyor Drive Models/Applications: 6620, 7720, 8820 Replaces: H110921 Belt, HKP, 1.5 x 157in OC Specifications Angle 30 Cord Type Polyester Effective Length (in) 0 Effective Length (mm) 0 Notched false Section HKP Outside Circumference (in) 0 Outside Circumference (mm) 0 Top Width (in) Top Width (mm)

Cleaning Fan Drive Models/Applications: 7720, 7721, 8820 Replaces: H108669 Belt, HJP, 1.25 x 69in OC Specifications Angle 30 Cord Type Polyester Effective Length (in) 0 Effective Length (mm) 0 Notched false Section HJP Outside Circumference (in) 0 Outside Circumference (mm) 0 Top Width (in) Top Width (mm)

Primary Countershaft & Separator Drive Models/Applications: 6600 (Sidehill-S/N 305673 & above), 7700 (404TH-01-S/N 8001 & above) Replaces: H108175 Belt, C2, 2.99 x 91in OC, 3 Band Specifications Angle 40 Cord Type Polyester Effective Length (in) 0 Effective Length (mm) 0 Notched false Section C2 Outside Circumference (in) 91 Outside Circumference (mm) 2311.4 Top Width (in) 2.991 Top Width (mm) 76

STRAW CHOPPER DRIVE Models/Applications: 6620, 6622, 7720, 7721, 8820, 9400 (Rear Operating Position), 9410 (Rear Operating Position), 9450 (Long, Rear) Replaces: H101436 Belt, C, 0.875 x 136in OC Specifications Angle 40 Cord Type Polyester Effective Length (in) 134.6 Effective Length (mm) 3418.8 Notched false Section C Outside Circumference (in) 136 Outside Circumference (mm) 3454.4 Top Width (in) 0.875 Top Width (mm) 22.2

Beater Drive (100% Beater Speed) Models/Applications: 9400, 9410, 9450, 9500, 9510, 9510SH, 9500SH, 9501, 9550, 9550SH, 9560, 9560SH, 9600, 9610, 9650, 9660 Replaces: AH139436 Belt, C, 0.875 x 79in OC Specifications Angle 40 Cord Type Polyester Effective Length (in) 77.6 Effective Length (mm) 1971 Notched false Section C Outside Circumference (in) 79 Outside Circumference (mm) 2006.6 Top Width (in) 0.875 Top Width (mm) 22.2

Traction Drive, Lower (Grain - 3 Speed) Models/Applications: 410, 510, 550 Replaces: 834174M1 Belt, HLK, 1.75 x 78in OC Specifications Angle 30 Cord Type Aramid - Kevlar Effective Length (in) 0 Effective Length (mm) 0 Notched false Section HLK Outside Circumference (in) 0 Outside Circumference (mm) 0 Top Width (in) Top Width (mm)

Traction, Upper & Drive (3 & 4 Speed) Models/Applications: 410 (Prior to S/N 1200006777), 510 (Prior to S/N 1201003653), 550 Replaces: 834110M1 Belt, HLK, 1.75 x 100.5in OC Specifications Angle 30 Cord Type Aramid - Kevlar Effective Length (in) 0 Effective Length (mm) 0 Notched false Section HLK Outside Circumference (in) 0 Outside Circumference (mm) 0 Top Width (in) Top Width (mm)
